DG409DYZ-T Real Image DG409DYZ-T Real Image1 DG409DYZ-T Real Image2 DG409DYZ-T Real Image3
Same model may have multiple batches, images only for reference.
DG409DYZ-T Real Image DG409DYZ-T Real Image1 DG409DYZ-T Real Image2 DG409DYZ-T Real Image3
DG409DYZ-T Real Image DG409DYZ-T Real Image1 DG409DYZ-T Real Image2 DG409DYZ-T Real Image3
Same model may have multiple batches, images only for reference.

DG409DYZ-T

Part No DG409DYZ-T
Manufacturer Intersil
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description IC MULTIPLEXER DUAL 4X1 16SOIC
Datasheet
DG409DYZ-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Intersil
Packaging Reel - TR
Status Active
Switch Circuit SP4T
Number of Circuits 2
Max On Resistance 100 Ohm
Channel-to-Channel Matching (ΔRon) 15 Ohm (Max)
Single Supply Voltage (V+) 5 V to 34 V
Dual Supply Voltage(V±) ±5 V to 20 V
Max Switch Time (Ton,Toff) 150ns, 150ns
Charge Injection 20pC
Channel Capacitance(CS off, CD off) 3pF, 14pF
Max Leakage Current (IS off) 500pA
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 16-SOIC
Win Source Part Number 1033241-DG409DYZ-T
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian DG409DYZ-T CAD Model

Description

The Intersil's DG409DYZ-T model is a 2-circuit SP4T switch circuit integrated circuit.

  • Package: Reel - TR
  • Maximum On-Resistance: 100 Ohms
  • Temperature Range: -40°C to 85°C (TA)
  • Charge Injection: 20pC
  • Channel-to-Channel Matching (ΔRon): 15 Ohm (Max)
  • Max Switch Time (Ton, Toff): 150ns, 150ns
  • Channel Capacitance (CS off, CD off): 3pF, 14pF
  • Max Leakage Current (IS off): 500pA
  • Popularity: Medium
  • Supply and Demand: Sufficient
