The WIPF201610P-R24ML from Inpaq is a high-performance, miniature multilayer chip antenna designed for wireless communication applications operating in the 2.4 GHz band. It is characterized by its compact size and excellent impedance matching, making it suitable for integration into space-constrained devices such as Bluetooth modules, Wi-Fi devices, and other wireless communication systems.

Applications:

• Bluetooth devices and modules
• Wi-Fi enabled devices
• Wireless sensors
• IoT (Internet of Things) devices
• Wearable electronics
• Remote control systems

Features:

• Compact size: 2.0 x 1.6 x 1.0 mm
• Surface mount technology (SMT) compatible
• 2.4 GHz ISM band operation
• High gain and efficiency
• Excellent impedance matching
• RoHS compliant

Benefits:

• Miniaturization: Enables smaller and more compact product designs.
• Ease of Integration: Simple to integrate into existing PCB designs due to its SMT compatibility.
• High Performance: Provides reliable wireless connectivity with high gain and efficiency.
• Cost-Effective: Offers a balance of performance and cost for mass production applications.
• Environmental Compliance: Meets RoHS standards, ensuring environmental safety.

Additional Details:

The WIPF201610P-R24ML antenna utilizes a multilayer ceramic construction, providing a rugged and stable performance over a wide range of operating temperatures. Its impedance matching is optimized for 50-ohm systems, ensuring efficient power transfer and minimizing signal reflections. The antenna's small footprint and low profile make it an ideal choice for devices where space is at a premium.

Specifically designed for the 2.4 GHz ISM band, this antenna supports various wireless protocols including Bluetooth, Wi-Fi (IEEE 802.11 b/g/n), and Zigbee. Its high gain ensures a strong and reliable connection even in challenging environments. The antenna is supplied in tape and reel packaging for automated assembly, reducing manufacturing costs and improving production efficiency.
