Products specifications

Manufacturer Infineon Technologies
Win Source Part Number 1269418-TLE4240-2M
Manufacturer Homepage www.infineon.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TLE4240-2M CAD Model

Description

The TLE4240-2M is a monolithic integrated low-dropout voltage regulator manufactured by Infineon Technologies. This regulator is specifically designed for automotive applications but can be used in any system requiring a stable 5V supply with low quiescent current and protection features. It offers excellent performance in harsh automotive environments, providing a reliable power supply for microcontrollers and other electronic components.

Applications

  • Automotive electronic control units (ECUs).
  • Microcontroller power supplies.
  • Sensor power supplies.
  • General-purpose voltage regulation.
  • Battery-powered systems.

Features

  • 5V output voltage.
  • Low dropout voltage.
  • Very low quiescent current.
  • Overtemperature protection.
  • Short-circuit protection.
  • Reverse polarity protection.
  • Wide input voltage range.

Benefits

  • Provides a stable and regulated 5V supply.
  • Extends battery life in automotive applications.
  • Protects the device from overtemperature, short-circuits, and reverse polarity.
  • Withstands harsh automotive environments.
  • Simplifies system design with integrated protection features.

Additional Details

The TLE4240-2M is designed with various protection features to ensure reliable operation in automotive environments. The overtemperature protection disables the output voltage if the chip temperature exceeds a certain threshold, preventing damage to the regulator. The short-circuit protection limits the output current in the event of a short circuit, protecting both the regulator and the connected load. The reverse polarity protection prevents damage from accidental reverse connection of the battery. The very low quiescent current minimizes power consumption when the regulator is in standby mode, extending battery life. The wide input voltage range allows the regulator to operate with a variety of automotive battery voltages. The TLE4240-2M is typically packaged in a PG-DSO-8 package. Refer to the Infineon Technologies datasheet for detailed electrical characteristics, application circuits, and package dimensions.
