IRGP4063DPBF

Name: IRGP4063DPBF
Brand: Infineon Technologies
SKU: 161290
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRGP4063DPBF
Manufacturer	Infineon Technologies
Catalog	IGBTs - Single
Description	IGBT 600V 96A 330W TO247AC
Datasheet	IRGP4063DPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Bulk
Status	Not For New Designs
IGBT Type	Trench
VCEO Maximum Collector-Emitter Breakdown Voltage	600V
Maximum Current Collector	96A
Pulsed Collector Current	144A
Collector-emitter saturation voltage(Max)	2.14V @ 15V, 48A
Maximum Power Dissipation	330W
Total Switching Energy(Ets)	625μJ (on), 1.28mJ (off)
Input Type	Standard
Gate Charge	95nC
Turn-on and Turn-off delay time	60ns/145ns
Testing Conditions	400V, 48A, 10 Ohm, 15V
Reverse Recovery Time (trr)	115ns
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	Through Hole
Case / Package	TO-247AC
Win Source Part Number	016697-IRGP4063DPBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	IRGP4063D
Introduction Date	May 11, 2006
ECCN	EAR99
Country of Origin	Mexico, Mexico
Halogen Free	Not Compliant
Estimated EOL Date	2024
Ultra Librarian 3D Model	Ultra Librarian IRGP4063DPBF CAD Model

Description

The Infineon Technologies 016697-IRGP4063DPBF is a trench IGBT transistor designed for use in Discrete Semiconductor Products. The device has a TO-247AC package and a maximum collector-emitter breakdown voltage of 600V.

Maximum Current Collector: 96A
Maximum Power Dissipation: 330W
Popularity: high
Supply and Demand: limited
Application: ideal solution for various applications requiring high current and voltage handling capabilities.
