IRG4PH50SPBF

Part No IRG4PH50SPBF
Manufacturer Infineon Technologies
Catalog IGBTs - Single
Description INSULATED GATE BIPOLAR TRANSISTOR | IGBT 1200V 57A 200W TO247AC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Bulk
Voltage - Collector Emitter Breakdown (Maximum) 1200V
Current - Collector (Ic) (Maximum) 57A
Current - Collector Pulsed (Icm) 114A
Vce(on) (Maximum) at Vge, Ic 1.7V at 15V, 33A
Maximum Power 200W
Switching Energy 1.8mJ (on), 19.6mJ (off)
Input Type Standard
Gate Charge 167nC
Td (on/off) at 25°C 32ns/845ns
Test Condition 960V, 33A, 5Ohm, 15V
Temperature Range - Operating -55°C ~ 150°C
Mounting Style Through Hole
Manufacturer Package TO-247-3
Supplier Device Package TO-247AC
Manufacturer Pack Quantity 25
MSL Level 1 (Unlimited)
Win Source Part Number 1188302-IRG4PH50SPBF
Manufacturer Homepage www.irf.com
Family Name IRG4PH50S
Introduction Date July 16, 2004
ECCN EAR99
Country of Origin Mexico
Halogen Free Compliant
Estimated EOL Date 2019
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRG4PH50SPBF CAD Model

Description

IRG4PH50SPBF from Infineon Technologies is a single IGBT used in power switching designs where engineers need efficient control of high-energy loads in compact, cost-sensitive systems. Devices in this category are commonly considered for motor drives, power conversion stages, UPS platforms, welding equipment, induction heating, and industrial inverters. For design teams, its value lies in the familiar IGBT switching architecture often selected when balancing conduction performance, drive simplicity, and ruggedness in established power topologies. Because the exact lifecycle status for IRG4PH50SPBF is information not available, procurement and sustaining teams should verify current manufacturer status before locking it into new designs or long-term service builds. RoHS compliance information is also not available from the provided input, so engineers should confirm the latest environmental compliance details directly through Infineon documentation, distributor compliance records, or the official datasheet before qualification, purchasing, or export-related compliance review.
