Same model may have multiple batches, images only for reference.

IRFBA1404PPBF

Name: IRFBA1404PPBF
Brand: Infineon Technologies
SKU: 604830
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	IRFBA1404PPBF
Manufacturer	Infineon Technologies
Catalog	FETs - Single
Description	AUTOMOTIVE MOSFET HEXFET® Power MOSFET \| MOSFET N-CH 40V 206A SUPER-220
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Tube
Transistor Polarity	N-Channel
Technology	MOSFET
Vds - Drain-Source Breakdown Voltage	40V
Id - Continuous Drain Current	206A
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Maximum) at Id, Vgs	3.7mOhm at 95A, 10V
Gate Source Voltage(th) (Maximum) at Id	4V at 250μA
Gate Charge (Qg) (Maximum) at Vgs	200nC at 10V
Gate Source Voltage (Maximum)	±20V
Input Capacitance (Ciss) (Maximum) at Vds	7360pF at 25V
Power Dissipation (Maximum)	300W
Temperature Range - Operating	-40°C ~ 175°C
Mounting Style	Through Hole
Supplier Device Package	SUPER-220 (TO-273AA)
Manufacturer Package	Super-220-3 (Straight Leads)
Manufacturer Pack Quantity	50
MSL Level	1 (Unlimited)
Win Source Part Number	1187518-IRFBA1404PPBF
Manufacturer Homepage	www.irf.com
Popularity	Medium
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian IRFBA1404PPBF CAD Model

Description

The IRFBA1404PPBF is a MOSFET from Infineon Technologies.

Popularity: Medium
Supply and Demand: Limited
Polarity: N-channel
Power Dissipation: 300W
Gate-Source Voltage(th): 4V @ 250μA
Package: Super-220 (TO-273AA)
Maximum Rds On: 3.7mOhm @ 95A, 10V
Application: Good choice for applications that require N-channel polarity MOSFETs.
