IR2136STRPBF Real Image IR2136STRPBF real image228
Same model may have multiple batches, images only for reference.
IR2136STRPBF Real Image IR2136STRPBF real image228
IR2136STRPBF Real Image IR2136STRPBF real image228
Same model may have multiple batches, images only for reference.

IR2136STRPBF

Part No IR2136STRPBF
Manufacturer Infineon Technologies
Catalog PMIC - Gate Drivers
Description IC DRIVER BRIDGE 3PHASE 28SOIC
Datasheet
IR2136STRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Driven Configuration Half-Bridge
Channel Type 3-Phase
Number of Drivers 6
Gate Type IGBT, N-Channel MOSFET
Supply Voltage - Operating 10 V to 20 V
Logic Voltage - VIL, VIH 0.8V, 3V
Current - Peak Output (Source, Sink) 200mA, 350mA
Input Type Inverting
High Side Voltage - Max (Bootstrap) 600V
Rise and Fall Time 125ns, 50ns
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 28-SOIC
Win Source Part Number 017371-IR2136STRPBF
Family Name IR2136
Introduction Date April 15, 2004
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2022
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IR2136STRPBF CAD Model

Description

The Infineon Technologies IR2136STRPBF is a 3-phase half-bridge gate driver IC with six drivers.

  • Gate Devices: IGBT and N-channel MOSFET
  • Bootstrap High Side Voltage: 600V
  • Supply Voltage: 10V to 20V
  • Peak Output Current (Source, Sink): 200mA and 350mA
  • Rise and Fall Time: 125ns and 50ns
  • Package: 28-SOIC
  • Operating Temperature Range: -40°C to 150°C
  • Popularity: High
  • Estimated EOL Date: 2022
  • Halogen-Free: Yes
  • ECCN: EAR99
  • Manufactured in: Malaysia
