IR2113PBF

Name: IR2113PBF
Brand: Infineon Technologies
SKU: 158860
Availability: InStock
Rating: 4.84 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IR2113PBF
Manufacturer	Infineon Technologies
Catalog	PMIC - Gate Drivers
Description	IC MOSFET DVR HI/LO SIDE 14-DIP
Datasheet	IR2113PBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Infineon Technologies
Packaging	Tube/Rail
Status	Active
Driven Configuration	Half-Bridge
Channel Type	Independent
Number of Drivers	2
Gate Type	IGBT, N-Channel MOSFET
Supply Voltage - Operating	3.3 V to 20 V
Logic Voltage - VIL, VIH	6V, 9.5V
Current - Peak Output (Source, Sink)	2A, 2A
Input Type	Non-Inverting
High Side Voltage - Max (Bootstrap)	600V
Rise and Fall Time	25ns, 17ns
Temperature Range - Operating	-40°C to 150°C (TJ)
Mounting	Through Hole
Case / Package	14-DIP
Win Source Part Number	017358-IR2113PBF
Family Name	IR2113
Introduction Date	March 26, 2004
ECCN	EAR99
Country of Origin	Thailand
Halogen Free	Compliant
Estimated EOL Date	2022
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian IR2113PBF CAD Model

Description

The Infineon Technologies IR2113PBF is a Half-Bridge driver with 2 number of drivers.

Drivers: 2
Gate Type: IGBT, N-Channel MOSFET
Input Type: Non-Inverting
Current Peak Output: 2A, 2A
Rise Time: 25ns
Fall Time: 17ns
Operating Temperature Range: -40°C to 150°C (TJ)
Supply Voltage Range: 3.3V to 20V
Case/Package: 14-DIP
Popularity: High
Supply and Demand Status: Balance
