IR2101STRPBF

Name: IR2101STRPBF
Brand: Infineon Technologies
SKU: 158820
Availability: InStock
Rating: 4.84 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IR2101STRPBF
Manufacturer	Infineon Technologies
Catalog	PMIC - Gate Drivers
Description	IC DRIVER HIGH/LOW SIDE 8SOIC
Datasheet	IR2101STRPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Driven Configuration	Half-Bridge
Channel Type	Independent
Number of Drivers	2
Gate Type	IGBT, N-Channel MOSFET
Supply Voltage - Operating	10 V to 20 V
Logic Voltage - VIL, VIH	0.8V, 3V
Current - Peak Output (Source, Sink)	210mA, 360mA
Input Type	Non-Inverting
High Side Voltage - Max (Bootstrap)	600V
Rise and Fall Time	100ns, 50ns
Temperature Range - Operating	-40°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-SOIC
Win Source Part Number	017343-IR2101STRPBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Family Name	IR2101
Introduction Date	June 25, 1996
ECCN	EAR99
Country of Origin	Thailand
Halogen Free	Compliant
Estimated EOL Date	2022
Ultra Librarian 3D Model	Ultra Librarian IR2101STRPBF CAD Model

Description

The Infineon Technologies IR2101STRPBF is a half-bridge gate driver IC designed for driving IGBT and N-channel MOSFET power devices.

Channels: Independent channels for high-side and low-side driving
Input Logic: Non-inverting input logic
Logic Voltage Range: 0.8V to 3V
Peak Output Current: 210mA and 360mA for source and sink, respectively
High-Side Voltage: Up to 600V
Operating Temperature Range: -40°C to 150°C
Package: 8-SOIC
Applications: Motor control, power supplies, and inverters
