Overview

The DF13C-5P-1.25V is a 5-position wire-to-board connector manufactured by Hirose Electric Co. Ltd. This connector features a 1.25mm pitch, making it suitable for compact electronic devices. It is designed for secure and reliable connections, providing a cost-effective solution for various applications.

Applications

• Power supply connections
• Signal connections in compact devices
• LED lighting systems
• Battery connections
• Robotics
• Consumer electronics

Features

• Number of Positions: 5
• Pitch: 1.25mm
• Mating Style: Wire-to-board
• Current Rating: (Consult Hirose datasheet for specific current rating)
• Voltage Rating: (Consult Hirose datasheet for specific voltage rating)
• Wire Gauge: (Consult Hirose datasheet for recommended wire gauge)
• Insulation Material: (Typically thermoplastic resin; consult datasheet)
• Contact Material: (Typically phosphor bronze or brass; consult datasheet)

Benefits

• Compact Design: The small 1.25mm pitch allows for high-density mounting on PCBs, saving space.
• Secure Connection: Provides a reliable electrical connection between the wires and the board.
• Cost-Effective: Offers a balance of performance and affordability.
• Easy to Use: Simple design facilitates easy wiring and mating.
• Versatile: Suitable for a wide range of applications.

Additional Details

The DF13 series from Hirose is a popular choice for wire-to-board connections in numerous applications. It is important to consult the official Hirose datasheet for detailed specifications, including the exact current and voltage ratings, applicable wire gauges, and mechanical dimensions. The mating connector part number is critical for proper function. This series provides a friction lock connection, often providing audible feedback to ensure a robust connection.
