BM10B(0.8)-20DP-0.4V(51) Real Image
Same model may have multiple batches, images only for reference.

BM10B(0.8)-20DP-0.4V(51)

Part No BM10B(0.8)-20DP-0.4V(51)
Manufacturer Hirose Electric Co Ltd
Catalog Circular Connectors - Housings
Description CONN HDR 20POS SMD GOLD / 20 Position Connector Header, Outer Shroud Contacts Surface Mount Gold
Datasheet
BM10B(0.8)-20DP-0.4V(51) Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)
Mfr Hirose Electric Co Ltd
Series BM10
Package Tape & Reel
Connector Type Header, Outer Shroud Contacts
Number of Positions 20
Pitch 0.016" (0.40mm)
Number of Rows 2
Mounting SMD (SMT)
Features Solder Retention
Contact Finish Gold
Contact Finish Thickness 2.00µin (0.051µm)
Mated Stacking Heights 0.8mm
Height Above Board 0.025" (0.63mm)
Base Product Number BM10B
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names BM10B0820DP04V51,684-6009-0-51,H11813CT,*BM10B(0.8)-20DP-0.4V(51),H11813DKR,H11813TR
Standard Package 8,000
Win Source Part Number 1049454-BM10B(0.8)-20DP-0.4V(51)
Ultra Librarian 3D Model Ultra Librarian BM10B(0.8)-20DP-0.4V(51) CAD Model

Description

The 1049454-BM10B(0.8)-20DP-0.4V(51) is a rectangular connector array that is used for edge type mezzanine (board to board) connections manufactured by Hirose Electric Co Ltd.

  • Series: BM10
  • Positions: 20
  • Pitch: 0.016" (0.40mm)
  • Connector Type: Header
  • Contacts: Outer Shroud
  • Rows: 2
  • Termination Feature: Solder Retention
  • Contact Finish: Gold
  • Contact Finish Thickness: 2.00μin (0.051μm)
  • Packaging: Tape and Reel
  • Standard Package: 8,000
  • ECCN: EAR99
  • HTSUS Code: 8536.69.4040
