The GD32F407VGT6 is a high-performance 32-bit microcontroller based on the ARM Cortex-M4 core with a Floating Point Unit (FPU). Operating at a frequency of up to 168 MHz, it delivers significant processing power for demanding applications. With its extensive set of peripherals, large memory capacity, and advanced features, it is suitable for a wide range of embedded systems requiring high performance and real-time capabilities.

Applications

• Industrial Automation Systems
• High-End Motor Control
• Advanced Robotics
• Digital Signal Processing (DSP)
• Medical Equipment
• Gaming Consoles

Features

• ARM Cortex-M4 core operating at 168 MHz
• 1024KB Flash Memory
• 192KB SRAM
• Floating-Point Unit (FPU)
• Three 12-bit ADCs (Analog-to-Digital Converters)
• Two 12-bit DACs (Digital-to-Analog Converters)
• Multiple Timers (General Purpose, Advanced Control)
• Communication Interfaces: USART, SPI, I2C, CAN, USB OTG
• Operating Voltage: 1.8V to 3.6V
• Operating Temperature: -40°C to +85°C

Benefits

• Extreme Performance: The 168 MHz Cortex-M4 core with FPU delivers exceptional processing power for complex applications.
• Large Memory Capacity: 1024KB Flash and 192KB SRAM enable large program storage and data manipulation.
• Enhanced Signal Processing: The integrated FPU accelerates floating-point calculations.
• Extensive Connectivity: Multiple communication interfaces enable seamless connectivity with various systems.
• Real-Time Capabilities: Suitable for applications requiring deterministic timing and control.

Additional Details

The GD32F407VGT6 operates from 1.8V to 3.6V and integrates a variety of power saving modes. It supports multiple communication interfaces including UARTs, SPIs, I2Cs, CAN, and USB OTG. The chip is offered in a LQFP100 package. It also includes an Ethernet MAC and camera interface. With a high level of integration and features, the GD32F407VGT6 is capable of fulfilling complex requirements of embedded systems.
