Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer GeneSiC Semiconductor
Packaging Bulk
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Maximum) 800V
Current - Average Rectified (Io) 2A
Voltage - Forward (Vf) (Maximum) at If 1.1V at 2A
Current - Reverse Leakage at Vr 10μA at 50V
Temperature Range - Operating -50°C ~ 150°C
Mounting Style Through Hole
Manufacturer Package 4-SIP, KBP
Supplier Device Package KBP
Manufacturer Pack Quantity 2,000
MSL Level 1 (Unlimited)
Win Source Part Number 1192674-KBP208
Manufacturer Homepage www.wontop.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian KBP208 CAD Model

Description

The GeneSiC Semiconductor KBP208 is a single-phase standard diode with a peak reverse voltage of 800V and an average rectified current of 2A.

  • Peak Reverse Voltage: 800V
  • Average Rectified Current: 2A
  • Voltage Forward: 1.1V @ 2A
  • Reverse Leakage Current: 10μA @ 50V
  • Package: 4-SIP, KBP
  • Operating Temperature: -50°C to 150°C
  • Category: Discrete Semiconductor Products
  • Manufacturer: Wontop
  • Manufactured In: China
  • Popularity: Medium
  • Supply and Demand: Balanced
  • Manufacturer Pack Quantity: 2,000
