Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer GeneSiC Semiconductor
Packaging Bulk
Diode Type Schottky
Voltage - DC Reverse (Vr) (Maximum) 40V
Current - Average Rectified (Io) 15A
Voltage - Forward (Vf) (Maximum) at If 500mV at 15A
Speed Fast Recovery = 200mA (Io)
Current - Reverse Leakage at Vr 10mA at 20V
Mounting Style Chassis, Stud Mount
Manufacturer Package DO-203AB, DO-5, Stud
Supplier Device Package DO-5
Operating Temperature - Junction -65°C ~ 150°C
Family Part Number 1N5828
Manufacturer Pack Quantity 250
MSL Level 1 (Unlimited)
Win Source Part Number 1122035-1N5828
Manufacturer Homepage www.transyselectronics.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 1N5828 CAD Model

Description

The GeneSiC Semiconductor 1N5828 is a Schottky diode manufactured by GeneSiC Semiconductor.

  • Current Rating: 15A
  • Reverse Leakage Current: 10mA @ 20V
  • Voltage Drop: 500mV @ 15A
  • Maximum DC Reverse Voltage: 40V
  • Package: DO-203AB, DO-5, stud
  • Mounting: Chassis or Stud
  • Operating Temperature: -65°C to 150°C
  • Classification: Discrete Semiconductor Products
  • Demand: Medium
  • Family: 1N5828
  • Manufacturer Pack Quantity: 250
