Part No XC56309VF100A
Manufacturer Freescale Semiconductor - NXP
Catalog Embedded - DSP (Digital Signal Processors)
Description 24-BIT DIGITAL SIGNAL PROCESSOR
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Embedded - DSP (Digital Signal Processors)
Mfr Freescale Semiconductor - NXP
Series DSP563xx
Package Bulk
Product Status Active
Type Fixed Point
Interface Host Interface, SSI, SCI
Clock Rate 100MHz
Non-Volatile Memory ROM (576B)
On-Chip RAM 24kB
Voltage - I/O 3.30V
Voltage - Core 3.30V
Temperature Range - Operating -40°C ~ 105°C (TJ)
Mounting Type Surface Mount
Package / Case 196-LBGA
Supplier Device Package 196-MAPBGA (15x15)
Base Product Number XC56
Standard Package 1 pcs
MSL Level 3 (168 Hours)
REACH Status Vendor Undefined
Win Source Part Number 903619-XC56309VF100A
Ultra Librarian 3D Model Ultra Librarian XC56309VF100A CAD Model

Description

The XC56309VF100A is a fixed-point digital signal processor (DSP) from the DSP563xx series by Freescale Semiconductor - NXP.

  • Clock Rate: 100MHz
  • Voltage Rating (I/O and Core): 3.30V
  • Package: 196-LBGA
  • Mounting: Surface Mount
  • Interfaces: Host interface, SSI, and SCI
  • On-chip ROM: 576B
  • RAM: 24kB
  • Temperature Range: -40°C to 105°C (TJ)
  • Status: Active
