MC9S12XS64CAE Real Image MC9S12XS64CAE real image2826
Same model may have multiple batches, images only for reference.
MC9S12XS64CAE Real Image MC9S12XS64CAE real image2826
MC9S12XS64CAE Real Image MC9S12XS64CAE real image2826
Same model may have multiple batches, images only for reference.

MC9S12XS64CAE

Part No MC9S12XS64CAE
Manufacturer Freescale Semiconductor - NXP
Catalog Embedded - Microcontrollers
Description IC MCU 16BIT 64KB FLASH 64LQFP / MCU 16-bit HCS12X CISC 64KB Flash 5V Automotive 64-Pin LQFP Tray
Datasheet
MC9S12XS64CAE Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer NXP
Packaging Tray
Status Active
Core Processor HCS12X
Part Core Size 16-Bit
Speed(Frequency) 40MHz
Number of I/O 44
Program Memory Size 64KB (64K x 8)
Program Memory Type FLASH
Data RAM Size 4K x 8
Supply Voltage - Operating 1.72 V to 5.5 V
Data Converters A/D 8x12b
Oscillator Type External
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 64-LQFP (10x10)
Win Source Part Number 133097-MC9S12XS64CAE
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 800
Family Name MC9S12XS64
Introduction Date September 18, 2008
ECCN 3A991.a.2
Country of Origin China, Philippines, Taiwan
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian MC9S12XS64CAE CAD Model

Description

The MC9S12XS64CAE is an integrated circuit microcontroller from NXP.

  • Family: Embedded - Microcontrollers
  • Category: Integrated Circuits
  • Program Memory Size: 64KB (64K x 8)
  • Program Memory Type: FLASH
  • Data Converters: 8x12b A/D
  • Temperature Range: -40°C to 85°C (TA)
  • Supply Voltage: 1.72 V to 5.5 V
  • Core Size: 16-bit
  • Data RAM Size: 4K x 8
  • Package: 64-LQFP (10x10)
