MC9S08AC16MFDE Real Image
Same model may have multiple batches, images only for reference.

MC9S08AC16MFDE

Part No MC9S08AC16MFDE
Manufacturer Freescale Semiconductor - NXP
Catalog Embedded - Microcontrollers
Description IC MCU 8BIT 16KB FLASH 48QFN / S08 series Microcontroller IC 8-Bit 40MHz 16KB (16K x 8) FLASH 48-QFN-EP (7x7)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs)>Embedded - Microcontrollers
Mfr Freescale Semiconductor
Series S08
Package Bulk
Core Processor S08
Core Size 8-Bit
Speed 40MHz
Connectivity I2C, SCI, SPI
Peripherals LVD, POR, PWM, WDT
Number of I/O 38
Program Memory Size 16KB (16K x 8)
Program Memory Type FLASH
RAM Size 1K x 8
Supply Voltage - Operating 2.7V ~ 5.5V
Data Converters A/D 8x10b
Oscillator Type Internal
Temperature Range - Operating -40°C ~ 125°C (TA)
Mounting SMD (SMT)
Package / Case 48-VFQFN Exposed Pad
Supplier Device Package 48-QFN-EP (7x7)
ECCN 3A991A2
HTSUS 8542.31.0001
Other Names 2156-MC9S08AC16MFDE-FR,FREFREMC9S08AC16MFDE
Standard Package 1
Win Source Part Number 1222977-MC9S08AC16MFDE
Ultra Librarian 3D Model Ultra Librarian MC9S08AC16MFDE CAD Model

Description

The Freescale Semiconductor - NXP component with the Win Source Part Number 1222977-MC9S08AC16MFDE is an integrated circuit that belongs to the S08 series.

  • Core Size: 8-bit
  • Speed: 40MHz
  • Package: Bulk
  • Standard Package: 1
  • Mounting: Surface-mount device (SMD)
  • I/O: 38
  • Program Memory Size: 16KB (16K x 8)
  • Program Memory Type: FLASH
  • Data Converter: A/D 8x10b
  • Oscillator Type: Internal
  • Operating Temperature: -40°C ~ 125°C (TA)
  • Operating Supply Voltage: 2.7V ~ 5.5V
