NC7SZ57P6X Real Image NC7SZ57P6X Real Image1 NC7SZ57P6X Real Image2
Same model may have multiple batches, images only for reference.
NC7SZ57P6X Real Image NC7SZ57P6X Real Image1 NC7SZ57P6X Real Image2
NC7SZ57P6X Real Image NC7SZ57P6X Real Image1 NC7SZ57P6X Real Image2
Same model may have multiple batches, images only for reference.

NC7SZ57P6X

Part No NC7SZ57P6X
Manufacturer Fairchild/ON Semiconductor
Catalog Logic - Gates and Inverters - Multi - Function, Configurable
Description IC LOGIC GATE UNIV 2INPUT SC70-6
Datasheet
NC7SZ57P6X Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Logic Type Configurable Multiple Function
Number of Circuits 1
Number of Inputs 2
Schmitt Trigger Input Yes
Output Type Single-Ended
Current - Output High, Low 32mA, 32mA
Supply Voltage - Operating 1.65 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package SC-70-6
Win Source Part Number 024843-NC7SZ57P6X
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name NC7SZ57
Introduction Date December 10, 1998
ECCN EAR99
Country of Origin China, Philippines, United States of America
Halogen Free Compliant
Estimated EOL Date 2024
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian NC7SZ57P6X CAD Model

Description

The NC7SZ57P6X is a configurable multiple function logic type integrated circuit manufactured by Fairchild/ON Semiconductor, the NC7SZ57P6X is a commonly used part.

  • Applications: Integrated Circuits
  • Temperature Range: -40°C to 85°C
  • Supply Voltage Operating Range: 1.65 V to 5.5 V
  • Circuits: 1
  • Package: SC-70-6
