HCPL0731R2 Real Image HCPL0731R2 Real Image
Same model may have multiple batches, images only for reference.
HCPL0731R2 Real Image HCPL0731R2 Real Image
HCPL0731R2 Real Image HCPL0731R2 Real Image
Same model may have multiple batches, images only for reference.

HCPL0731R2

Part No HCPL0731R2
Manufacturer Fairchild/ON Semiconductor
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOCOUPLER DARL 2CHAN 8SOIC
Datasheet
HCPL0731R2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Number of Channels 2
Isolation Voltage 2500Vrms
Minimum DC Current Transfer Ratio 400% @ 500μA
Maximum DC Current Transfer Ratio 5000% @ 500μA
Switching Turn-On and Turn-Off Time 300ns, 1.6μs
Input Type DC
Output Type Darlington
Maximum Output Voltage 18V
Channel Output Current 60mA
Forward Voltage 1.35V
Continuous forward current- Max 20mA
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SO Tall
Win Source Part Number 1042564-HCPL0731R2
Popularity Medium
Supply and Demand Status Balance
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian HCPL0731R2 CAD Model

Description

The Fairchild/ON Semiconductor HCPL0731R2 is a two-channel DC input Darlington output optocoupler with an isolation voltage of 2500Vrms.

  • Isolation Voltage: 2500Vrms
  • Minimum DC Current Transfer Ratio: 400% @ 500μA
  • Maximum DC Current Transfer Ratio: 5000% @ 500μA
  • Switching Turn-On Time: 300ns
  • Switching Turn-Off Time: 1.6μs
  • Maximum Output Voltage: 18V
  • Channel Output Current: 60mA
  • Temperature Range: -40°C to 85°C
