Same model may have multiple batches, images only for reference.
FSFR1700USL Fairchild/ON Semiconductor
Same model may have multiple batches, images only for reference.

FSFR1700USL

Part No FSFR1700USL
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - AC DC Converters, Offline Switchers
Description IC FPS POWER SWITCH 9-SIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Not For New Designs
Output Isolation Isolated
Internal Switch(s) Yes
Voltage - Breakdown 500V
Topology Half-Bridge
Voltage - Start Up 12.5V
Supply Voltage - Operating 10 V to 25 V
Duty Cycle 50%
Frequency - Switching Up to 300kHz
Power (Watts) 200W
Fault Protection Current Limiting, Over Temperature, Over Voltage
Control Features Frequency Control
Temperature Range - Operating -40°C to 130°C (TJ)
Case / Package 9-SIP (L forming)
Mounting Through Hole
Win Source Part Number 204338-FSFR1700USL
Popularity Medium
Supply and Demand Status Limited
Quantity per package 19
Ultra Librarian 3D Model Ultra Librarian FSFR1700USL CAD Model

Description

The FSFR1700USL is an integrated circuit from Fairchild/ON Semiconductor.

  • Topology: Half-Bridge
  • Features: Output Isolation, Internal Switches
  • Voltage Breakdown: 500V
  • Operating Temperature: -40°C to 130°C
  • Power: 200W
  • Switching Frequency: Up to 300kHz
  • Fault Protection: Current Limiting, Over Temperature, Over Voltage
  • Frequency Control: Yes
  • Supply Voltage: 10V to 25V
  • Status: Limited Supply and Demand, Not for New Designs
