FAN5330SX

Part No FAN5330SX
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - LED Drivers
Description IC LED DRIVER RGLTR DIM SOT23-5
Datasheet
FAN5330SX Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Obsolete(EOL)
Type DC DC Regulator
Topology Step-Up (Boost)
Internal Switch(s) Yes
Number of Outputs 1
Operating Input Voltage(Min) 1.8V
Maximum Supply Voltage 5.5V
Output Voltage 30V
Channel Output Current 35mA
Frequency 1.5MHz
Dimming PWM
Applications Backlight
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package SOT-23-5
Win Source Part Number 066847-FAN5330SX
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian FAN5330SX CAD Model

Description

FAN5330SX

The FAN5330SX is a current-mode PWM boost controller intended for applications requiring a step-up voltage conversion. It provides seamless performance across multiple settings.

  • Applications:
    • LCD Bias Supplies
    • LED Backlight Drivers
    • Portable Meters
  • Features and Benefits:
    • High Switching Frequency: Allows the use of smaller inductors for a compact design.
    • Current-Mode Operation: Ensures superior line and load regulation.
    • Integrated Soft-Start: Minimizes inrush current during startup.
  • Additional Details:
    • Thermal Shutdown Protection
    • External Clock Synchronization
    • Optimized for Low-Power Applications
