Overview

The FAN3224TMX high-speed, low-side gate driver delivers outstanding performance for switching MOSFETs or IGBTs in fast-switching applications. It has minimal propagation delay and high current-driving capabilities, making it ideal for efficiency-driven designs.

Features and Benefits

• High Current Drive Capacity: Capable of sourcing and sinking 4A peak currents, ensuring quick switching transitions.
• Ultra-low Propagation Delay: Provides propagation delays of less than 25ns, optimizing performance for high-frequency applications.
• Wide Operating Voltage Range: Supports a voltage range of 4.5V to 18V, ensuring compatibility with various power supplies.

Applications

• DC-DC Converters
• Motor Drives
• Power Supplies
• Class D Amplifiers
