2N7002DW Real Image

2N7002DW Real Image

2N7002DW Real Image

Same model may have multiple batches, images only for reference.

2N7002DW Real Image

2N7002DW Real Image

Same model may have multiple batches, images only for reference.

2N7002DW

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	2N7002DW
Manufacturer	Fairchild/ON Semiconductor
Catalog	FETs - Arrays
Description	MOSFET 2N-CH 60V 0.115A SC70-6
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Fairchild Semiconductor
Standard Package	1
Category	Discrete Semiconductor Products
Family	FETs - Arrays
Packaging	Reel
FET Type	2 N-Channel (Dual)
FET Feature	Logic Level Gate
Drain to Source Voltage (Vdss)	60V
Current - Continuous Drain (Id) @ 25°C	115mA
Rds On (Max) @ Id Vgs	7.5 Ohm @ 50mA 5V
Vgs(th) (Max) @ Id	2V @ 250µA
Input Capacitance (Ciss) @ Vds	50pF @ 25V
Power - Max	200mW
Operating Temperature Range	-55°C ~ 150°C (TJ)
Mounting Style	SMD/SMT
Package	6-TSSOP SC-88 SOT-363
Manufacturer Device Package	SC-70-6
Catalog	N-Channel Logic Level Gate FETs
Win Source Part Number	084199-2N7002DW
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Application Field	Used in Industrial, Power Management
Ultra Librarian 3D Model	Ultra Librarian 2N7002DW CAD Model

Description

Overview

The 2N7002DW is a high-efficiency dual N-channel MOSFET designed for complex electronic symmetries. It's ideal for circuits requiring coordinated switching actions.

Applications

H-bridge motor drivers
Signal modulation circuits
Multiplexer functions

Features and Benefits

Dual MOSFET configuration
Low on-resistance for reduced loss
Fast dynamic response
Space-saving package design

This component is excellent for high-precision tasks, offering reliable switching under varied electronic conditions.
