5978018601 FAIR-RITE PRODUCTS – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

5978018601

Part No 5978018601
Manufacturer FAIR-RITE PRODUCTS
Catalog Ferrite Cores
Description FERRITE CORE TOROID 78
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Core Type Toroid
Material 78
Tolerance ±25%
Gap Ungapped
Initial Permeability (µi) 2300
Effective Length (le) mm 98.0
Effective Area (Ae) mm2 178.0
Effective Magnetic Volume (Ve) mm3 17500.0
Finish Uncoated
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1528102-5978018601
Ultra Librarian 3D Model Ultra Librarian 5978018601 CAD Model
