The PT7M7823STAEX is a high-performance, versatile microprocessor supervisory circuit from the leading semiconductor manufacturer, Diodes Incorporated. This compact and reliable component is designed to monitor the power supplies in microprocessor and digital systems, providing a crucial safeguard against power failures and ensuring the stability and functionality of electronic devices.

Key Features

• Precision Voltage Monitoring: The PT7M7823STAEX offers precise monitoring of fixed voltages, ensuring that systems are protected from undervoltage conditions.
• Low Power Consumption: With its low power consumption, this supervisory circuit is ideal for power-sensitive applications, contributing to the overall energy efficiency of the system.
• Manual Reset Input: The inclusion of a manual reset input provides an additional layer of control, allowing for system resets on demand.
• Reset Timeout Delay: It features a programmable delay time for the reset output, which can be tailored to meet the specific requirements of the application.
• High Accuracy: The device is engineered for high-accuracy operation, ensuring reliable monitoring and control of system voltages.

Applications

The PT7M7823STAEX is suitable for a wide range of applications, including but not limited to:

• Computers and Servers
• Portable/Battery-Powered Equipment
• Embedded Systems
• Industrial Controllers
• Telecommunications Equipment

Product Specifications

Packaged in a compact SOT-23 package, the PT7M7823STAEX is designed for surface mount technology, facilitating ease of integration into a variety of circuit designs. It operates over a wide temperature range, making it suitable for harsh environments. The device's active-low reset output ensures compatibility with most microprocessors, providing a reliable reset signal whenever necessary.

Diodes Incorporated's commitment to quality and performance is evident in the PT7M7823STAEX supervisory circuit, making it a top choice for designers looking for a robust power monitoring solution.
