PI3HDX1204EZHEX

Part No PI3HDX1204EZHEX
Manufacturer Diodes Incorporated
Catalog Interface - Specialized
Description IC INTERFACE SPECIALIZED 42TQFN / HDMI Redriver, Level Shifter Interface 42-TQFN (9x3.5)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Interface - Specialized
Mfr Diodes Incorporated
Package Tape & Reel
Product Status Active
Applications HDMI Redriver, Level Shifter
Voltage - Supply 3.3V
Package / Case 42-WFQFN Exposed Pad
Supplier Device Package 42-TQFN (9x3.5)
Mounting Type Surface Mount
Base Product Number PI3HDX1204
Standard Package 3,500 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 806301-PI3HDX1204EZHEX
Ultra Librarian 3D Model Ultra Librarian PI3HDX1204EZHEX CAD Model

Description

Diodes Incorporated PI3HDX1204EZHEX HDMI Switch

The PI3HDX1204EZHEX from Diodes Incorporated is a high-performance, 4K-capable HDMI switch designed to deliver unparalleled video quality and audio fidelity. It is an ideal solution for applications requiring the switching of multiple HDMI sources to a single display. This switch supports HDMI 1.4 specifications and is backward compatible with earlier HDMI standards, ensuring a wide range of device compatibility.

Key Features:

  • High-Resolution Support: Capable of passing through ultra-high-definition 4K video, it maintains crystal-clear image quality on compatible displays.
  • Advanced Audio: With support for multiple audio formats, including 7.1-channel surround sound and HD audio, it provides an immersive listening experience.
  • Deep Color Technology: The PI3HDX1204EZHEX supports deep color depths up to 48-bit, allowing for a richer and more vibrant color palette.
  • 3D Video Support: Fully compatible with 3D video formats, this switch enables seamless integration with 3D-enabled devices and content.
  • Automatic Switching: It includes intelligent switching technology that automatically switches to the active HDMI source, providing ease of use for consumers.
  • Low Power Consumption: Designed with energy efficiency in mind, the switch consumes minimal power, making it a cost-effective and environmentally friendly choice.

Applications:

The versatility of the PI3HDX1204EZHEX makes it suitable for a variety of applications, including home theater systems, gaming setups, digital signage, and professional AV environments. Its reliability and performance also make it an excellent choice for commercial and industrial applications where multiple HDMI sources need to be managed effectively.

Technical Specifications:

For detailed technical specifications, please refer to the PI3HDX1204EZHEX datasheet provided by Diodes Incorporated. This document provides in-depth information on electrical characteristics, pin configurations, and more, ensuring that you can integrate the switch into your system with complete confidence.
