Diodes Incorporated introduces the AH276Z4-CG1, a versatile and high-performance Hall Effect sensor designed for a wide range of applications. This sensor is a crucial component in modern electronic systems, offering precise and reliable magnetic field detection.

Key Features

• High Sensitivity: The AH276Z4-CG1 has been engineered to detect the presence of magnetic fields with high accuracy, making it suitable for applications that require precise measurement.
• Wide Operating Voltage Range: This sensor operates over a wide voltage range, from 3.5V to 20V, accommodating various power supply requirements and ensuring versatility across different electronic platforms.
• Low Power Consumption: Designed for efficiency, the AH276Z4-CG1 consumes minimal power, which is ideal for battery-powered or energy-sensitive systems.
• Open-Drain Output: The open-drain output allows for simple interfacing with other circuitry and provides the flexibility to connect multiple sensors in parallel.
• Chopper Stabilized Design: The inclusion of chopper stabilization enhances the stability of the sensor output against temperature variations and external disturbances, ensuring consistent performance over time.

Applications

The AH276Z4-CG1 is well-suited for a diverse range of applications, including but not limited to:

• Position and proximity sensing
• Rotation and speed detection in motors and fans
• Flow meters
• Encoders
• Contactless switches

Quality and Reliability

Diodes Incorporated is committed to providing high-quality and reliable components. The AH276Z4-CG1 is no exception, undergoing rigorous testing to meet stringent industry standards. Its robust design ensures long-term reliability in a variety of environmental conditions.

Package and Availability

The AH276Z4-CG1 is available in a compact SIP-3 (Single Inline Package) that is easy to mount on a printed circuit board. This package is ideal for space-constrained applications while providing excellent thermal performance. For pricing and availability, please contact Diodes Incorporated or an authorized distributor.
