Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Approvals UL
Mounting SMD (SMT)
Case / Package 0302
Color Yellow
Current 10 mA
Current Rating 12 mA
Forward Current 12 mA
Forward Voltage 5 V
Illumination Color Yellow
Length 12.85 mm
Lens Color Yellow
Lens Style Dome
Life (Hours) 100000 hours
Luminous Intensity 12.6 mcd
Maximum Operating Temperature 85 °C
Min Operating Temperature -40 °C
Mount Front, Snap in
Number of LEDs 1
Number of Pins 2
Operating Supply Voltage 5 V
Packaging Bulk
REACH SVHC No SVHC
RoHS Compliant
Schedule B 8541402000, 8541402000
Termination Wire
Viewing Angle 60 °
Voltage 5 V
Voltage Rating 5 V
Voltage Rating (DC) 5 V
Wavelength 585 nm
Win Source Part Number 1035052-558-0302-003F
Categories Optics - LEDs - Light Pipes
Manufacturer Dialight
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 558-0302-003F CAD Model

Description

The LED is a high-quality electronic component with a voltage rating of 5 V and a current rating of 12 mA manufactured by Dialight.

  • Voltage Rating: 5 V
  • Current Rating: 12 mA
  • Luminous Intensity: 12.6 mcd
  • Viewing Angle: 60 degrees
  • Wavelength: 585 nm
  • Lens Color: Yellow
  • Forward Voltage: 5 V
  • Forward Current: 12 mA
  • Maximum Operating Temperature: 85 degrees Celsius
  • Minimum Operating Temperature: -40 degrees Celsius
  • Life: 100000 hours
  • RoHS Compliant: Yes
  • Mounting: SMD (SMT)
  • Case/Package: 0302
  • Length: 12.85 mm
  • Approvals: UL
  • Application: Optics, LEDs, and Light Pipes
