CY8C29866-24AXI Real Image CY8C29866-24AXI Real Image1 CY8C29866-24AXI Real Image2 CY8C29866-24AXI Real Image3
Same model may have multiple batches, images only for reference.
CY8C29866-24AXI Real Image CY8C29866-24AXI Real Image1 CY8C29866-24AXI Real Image2 CY8C29866-24AXI Real Image3
CY8C29866-24AXI Real Image CY8C29866-24AXI Real Image1 CY8C29866-24AXI Real Image2 CY8C29866-24AXI Real Image3
Same model may have multiple batches, images only for reference.

CY8C29866-24AXI

Part No CY8C29866-24AXI
Manufacturer Cypress Semiconductor Corp
Catalog Embedded - Microcontrollers
Description IC MCU 8BIT 32KB FLASH 100TQFP / MCU 8-bit M8C 32KB Flash 3.3V/5V 100-Pin TQFP Tray
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Cypress Semiconductor Corp
Standard Package 450
Category Integrated Circuits(ICs)
Family Embedded - Microcontrollers
Series PSOC1 CY8C29xxx
Packaging Tray
Core Processor M8C
Core Size 8-Bit
Speed 24MHz
Connectivity I²C SPI UART/USART
Peripherals POR PWM WDT
Number of I/O 64
Program Memory Size 32KB (32K x 8)
Program Memory Type FLASH
RAM Size 2K x 8
Operating Supply Voltage 3 V ~ 5.25 V
Data Converters A/D 4x14b; D/A 4x9b
Oscillator Type Internal
Operating Temperature Range -40°C ~ 85°C (TA)
Package 100-LQFP
Manufacturer Device Package 100-TQFP (14x14)
Catalog PSOC 1 CY8C29x66
Win Source Part Number 080289-CY8C29866-24AXI
Popularity Medium
Supply and Demand Status Limited
Family Name CY8C29666
Introduction Date November 12, 2004
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian CY8C29866-24AXI CAD Model

Description

CY8C29866-24AXI Microcontroller

The CY8C29866-24AXI provides advanced processing capabilities tailored for both detailed and high-level system integrations. Ideal for dynamic and demanding applications across multiple sectors.

  • Features and Benefits:
    • Enhanced PSoC processing with increased memory capacity
    • Optimized power usage for sustainable design
    • Scalable interfaces allowing for flexible connectivity
  • Applications and Projects:
    • Smart home devices
    • Automotive control systems
    • Industrial sensing solutions
  • Additional Details:
    • Package: TQFP-100
    • Compliance with all major environmental standards
