C4D08120E Cree Inc.
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr Cree/Wolfspeed
Series Z-Rec®
Package Tube
Product Status Active
Technology SiC (Silicon Carbide) Schottky
Voltage - DC Reverse (Vr) (Max) 1200 V
Current - Average Rectified (Io) 24.5A
Voltage - Forward (Vf) (Max) @ If 3 V @ 2 A
Speed No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr) 0 ns
Current - Reverse Leakage @ Vr 250 µA @ 1200 V
Capacitance @ Vr, F 560pF @ 0V, 1MHz
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Supplier Device Package TO-252-2
Operating Temperature - Junction -55°C ~ 175°C
Base Product Number C4D08120
Standard Package 75 pcs
MSL Level 3 (168 Hours)
ECCN EAR99
HTSUS 8541.10.0080
California Prop 65 Warning Information
Win Source Part Number 575822-C4D08120E
Ultra Librarian 3D Model Ultra Librarian C4D08120E CAD Model

Description

The 575822-C4D08120E is a SiC (Silicon Carbide) Schottky diode from the Z-Rec™ series.

  • Series: Z-Rec™
  • Application: Rectifier
  • Maximum DC Reverse Voltage (Vr): 1200V
  • Average Rectified Current (Io): 24.5A
  • Forward Voltage (Vf): 3V @ 2A
  • Reverse Recovery Time (trr): 0ns
  • Package: TO-252-3
  • Mounting: Surface Mount

With its excellent performance and reliability, the 575822-C4D08120E is an ideal choice for rectifier applications in various electronic systems.
