C3D04060E-TR Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Cree/Wolfspeed
Series Z-Rec
Packaging Reel package
Diode Type Schottky
Voltage - DC Reverse (Vr) (Maximum) 600V
Current - Average Rectified (Io) 15.5A
Voltage - Forward (Vf) (Maximum) @ If 1.8V @ 4A
Speed Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 50μA @ 600V
Capacitance @ Vr, F 251pF @ 0V, 1MHz
Mounting SMD
Package TO-252-3, DPak (2 Leads + Tab), SC-63
Manufacturer Package TO-252-2
Operating Temperature - Junction -55°C ~ 175°C
Win Source Part Number 770967-C3D04060E-TR
Popularity Medium
Supply and Demand Status Limited
Family Name C3D04060E
Introduction Date September 02, 2015
ECCN EAR99
Country of Origin United States of America
Ultra Librarian 3D Model Ultra Librarian C3D04060E-TR CAD Model

Description

The C3D04060E-TR is a Schottky Diode manufactured by Cree/Wolfspeed. It has a DC reverse voltage of 600V and a forward voltage of 1.8V @ 4A.

  • Reverse Voltage: 600V
  • Forward Voltage: 1.8V @ 4A
  • Diode Type: Schottky
  • Fast Recovery Time: 200mA (Io)
  • Average Rectified Current: 15.5A
  • Reverse Leakage Current: 50μA @ 600V
  • Operating Temperature: -55°C to 175°C
  • Package: TO-252-3, DPak (2 Leads + Tab), SC-63
