Same model may have multiple batches, images only for reference.

SLPX102M160C7P3

Name: SLPX102M160C7P3
Brand: Cornell Dubilier Electronics (CDE)
SKU: 1307806
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	SLPX102M160C7P3
Manufacturer	Cornell Dubilier Electronics (CDE)
Catalog	Aluminum Capacitors
Datasheet	SLPX102M160C7P3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Capacitors>Aluminum Electrolytic Capacitors
Mfr	Cornell Dubilier Electronics (CDE)
Series	SLPX
Package	Bulk
Capacitance	1000 µF
Tolerance	±20%
Voltage - Rated	160 V
ESR (Equivalent Series Resistance)	199mOhm @ 120Hz
Lifetime @ Temp.	3000 Hrs @ 85°C
Temperature Range - Operating	-40°C ~ 85°C
Polarization	Polar
Applications	General Purpose
Ripple Current @ Low Frequency	3 A @ 120 Hz
Ripple Current @ High Frequency	4.41 A @ 20 kHz
Lead Spacing	0.394" (10.00mm)
Dimension	0.984" Dia (25.00mm)
Height - Seated (Max)	1.575" (40.00mm)
Mounting Type	Through Hole
Package / Case	Radial, Can - Snap-In
Other Names	SLPX102M160C7P3,338-1555
Standard Package	100
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8532.22.0040
Win Source Part Number	1307806-SLPX102M160C7P3
Ultra Librarian 3D Model	Ultra Librarian SLPX102M160C7P3 CAD Model

Description

The SLPX102M160C7P3 is a 1000μF, 160V aluminum electrolytic capacitor from Cornell Dubilier Electronics.

Capacitance: 1000μF
Voltage: 160V
Applications: General purpose
Tolerance: ±20%
ESR: 199mOhm @ 120Hz
Ripple Current: 3A @ 120Hz and 4.41A @ 20kHz
Lifetime: 3000 hours @ 85°C
Polarization: Polarized
Package: Radial, can-snap-in
Mounting: Through-hole
Height: 1.575" (40.00mm)
Lead Spacing: 0.394" (10.00mm)
