SLP392M063C7P3 Real Image
Same model may have multiple batches, images only for reference.

SLP392M063C7P3

Part No SLP392M063C7P3
Manufacturer Cornell Dubilier Electronics (CDE)
Catalog Aluminum Capacitors
Datasheet
SLP392M063C7P3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors>Aluminum Electrolytic Capacitors
Mfr Cornell Dubilier Electronics (CDE)
Series SLP0712TE (750W)
Package Bulk
Capacitance 3900 µF
Tolerance ±20%
Voltage - Rated 63 V
ESR (Equivalent Series Resistance) 102mOhm @ 120Hz
Lifetime @ Temp. 3000 Hrs @ 105°C
Temperature Range - Operating -40°C ~ 105°C
Polarization Polar
Applications General Purpose
Ripple Current @ Low Frequency 2.57 A @ 120 Hz
Ripple Current @ High Frequency 3.21 A @ 20 kHz
Lead Spacing 0.394" (10.00mm)
Dimension 0.984" Dia (25.00mm)
Height - Seated (Max) 1.575" (40.00mm)
Mounting Type Through Hole
Package / Case Radial, Can - Snap-In
Standard Package 100
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0040
Win Source Part Number 1307914-SLP392M063C7P3
Ultra Librarian 3D Model Ultra Librarian SLP392M063C7P3 CAD Model

Description

The Cornell Dubilier Electronics SLP392M063C7P3 is a radial, can-snap-in aluminum electrolytic capacitor. It has a capacitance of 3900 µF and a voltage rating of 63 V. This capacitor has a tolerance of ±20% and an ESR of 102mOhm @ 120Hz. The Cornell Dubilier Electronics SLP392M063C7P3 has a ripple current of 2.57 A @ 120 Hz and 3.21 A @ 20 kHz. It has a lifetime of 3000 hours @ 105°C.
