Same model may have multiple batches, images only for reference.
XGL3530-122MEC Real Image
Same model may have multiple batches, images only for reference.

XGL3530-122MEC

Part No XGL3530-122MEC
Manufacturer Coilcraft
Catalog Fixed Inductors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr COILCRAFT
Series XGL3530
Package Strip
Type Molded
Inductance 1.2 µH
Tolerance ±20%
Current Rating (Amps) 10.4 A
Current - Saturation (Isat) 5.6A
Shielding Shielded
DC Resistance (DCR) 12.8mOhm Max
Frequency - Self Resonant 73MHz
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 1 MHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.138" L x 0.126" W (3.50mm x 3.20mm)
Height - Seated (Max) 0.118" (3.00mm)
Other Names 2457-XGL3530-122MEC
REACH Status Vendor Undefined
Win Source Part Number 1272967-XGL3530-122MEC
Ultra Librarian 3D Model Ultra Librarian XGL3530-122MEC CAD Model

Description

The XGL3530-122MEC is a molded fixed inductor from COILCRAFT.

  • Series: XGL3530
  • Package: Shielded in strip form
  • Inductance: 1.2 microhenries
  • Tolerance: +/- 20%
  • Rated: AEC-Q200
  • DC Resistance: 12.8 milliohms maximum
  • Current Rating: 10.4A
  • Saturation Current: 5.6A
  • Temperature Range: -40 to 125 degrees Celsius
  • Dimension: 0.138 inches in length and 0.126 inches in width
