Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer CEL
Part Status Obsolete(EOL)
Frequency 2.4GHz ~ 2.5GHz
Gain 23dB
RF Type Bluetooth
Operating Supply Voltage 2.7 V ~ 3.6 V
Operating Supply Current 120mA
Package 12-XFQFN Exposed Pad
Manufacturer Package 12-TSQFN (2x2)
Win Source Part Number 798902-UPG2301T5L-E2-A
Popularity Medium
Supply and Demand Status Balance
Family Name UPG2301T5L
Introduction Date November 06, 2009
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian UPG2301T5L-E2-A CAD Model

Description

The CEL UPG2301T5L-E2-A RF amplifier from CEL is used for Bluetooth and has a gain of 23dB and a frequency range of 2.4GHz to 2.5GHz.

  • Operating Supply Voltage: 2.7V to 3.6V
  • Operating Supply Current: 120mA
  • Introduction Date: November 06, 2009
  • Status: Obsolete (EOL)
  • Supply and Demand Status: Balance
  • Package: 12-TSQFN (2x2)
  • Category: RF/IF and RFID
