HSMS-8202-TR1G Real Image HSMS-8202-TR1G real image4632
Same model may have multiple batches, images only for reference.
HSMS-8202-TR1G Real Image HSMS-8202-TR1G real image4632
HSMS-8202-TR1G Real Image HSMS-8202-TR1G real image4632
Same model may have multiple batches, images only for reference.

HSMS-8202-TR1G

Part No HSMS-8202-TR1G
Manufacturer Broadcom Limited
Catalog RF Diodes
Description RF Diode Schottky 4V 75mW 3-Pin SOT-23 T/R / DIODE SCHOTTKY MIXER 4V SOT-23
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Diode Type Schottky - 1 Pair Series Connection
Voltage - Peak Reverse (Max) 4V
Capacitance @ Vr, F 0.26pF @ 0V, 1MHz
Resistance @ If, F 14 Ohm @ 5mA, 1MHz
Power Dissipation (Max) 75mW
Temperature Range - Operating 150°C (TJ)
Case / Package SOT-23-3
Win Source Part Number 017067-HSMS-8202-TR1G
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 3k pcs
Family Name HSMS-8202
Introduction Date April 01, 2004
ECCN EAR99
Country of Origin Thailand, Malaysia
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian HSMS-8202-TR1G CAD Model

Description

The HSMS-8202-TR1G is a Schottky 1 pair series connection diode manufactured by Broadcom Limited.

  • Voltage Peak Reverse: 4V
  • Power Dissipation: 75mW
  • Capacitance: 0.26pF at 0V, 1MHz
  • Resistance: 14 Ohm at 5mA, 1MHz
  • Family Name: HSMS-8202
  • Temperature Range: 150°C (TJ)
  • Package: SOT-23-3
