HCPL-6651 Real Image
Same model may have multiple batches, images only for reference.

HCPL-6651

Part No HCPL-6651
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description Optocoupler Logic-Out Open Collector DC-IN 4-CH 16-Pin CFPAK / Hermetically Sealed, High Speed, High CMR, Logic Gate Optocouplers | OPTOISO 1.5KV OPEN COLL 16FLATPK
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube
Number of Channels 4
Inputs - Side 1/Side 2 4/0
Voltage - Isolation 1500VDC
Common Mode Transient Immunity (Minimum) 1kV/μs
Input Type DC
Output Type Open Collector, Schottky Clamped
Current - Output / Channel 25mA
Data Rate 10MBd
Propagation Delay tpLH / tpHL (Maximum) 100ns, 100ns
Rise / Fall Time 35ns, 35ns
Voltage - Forward (Vf) 1.5V
Current - DC Forward (If) (Maximum) 20mA
Supply Voltage (V) 4.5V ~ 5.5V
Temperature Range - Operating -55°C ~ 125°C
Mounting Style SMD
Manufacturer Package 16-Flatpack
Supplier Device Package 16-Flatpack
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 758693-HCPL-6651
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name HCPL-6651
Introduction Date October 22, 2000
ECCN EAR99
Country of Origin Singapore
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian HCPL-6651 CAD Model

Description

The Broadcom Limited HCPL-6651 is a four-channel optocoupler. It is designed for use in DC input applications with an output type of open collector, Schottky clamped.

  • Data Rate: 10MBd
  • Voltage Isolation: 1500VDC
  • Input Type: DC
  • Current Output per Channel: 25mA
  • Package: 16-flatpack
  • Operating Temperature: -55°C ~ 125°C
  • Rise/Fall Time: 35ns
  • Forward Voltage: 1.5V
  • Popularity: High
  • Estimated EOL Date: 2027
  • Halogen-Free: Compliant
