HCPL-2630-500E Real Image HCPL-2630-500E real image15487
Same model may have multiple batches, images only for reference.
HCPL-2630-500E Real Image HCPL-2630-500E real image15487
HCPL-2630-500E Real Image HCPL-2630-500E real image15487
Same model may have multiple batches, images only for reference.

HCPL-2630-500E

Part No HCPL-2630-500E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 3.75KV OPEN COLL 8DIP GW
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 2
Inputs - Side 1/Side 2 2/0
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 5kV/μs
Input Type DC
Output Type Open Collector, Schottky Clamped
Channel Output Current 50mA
Data Rate 10MBd
Propagation Delay tpLH / tpHL (Max) 100ns, 100ns
Rise and Fall Time 24ns, 10ns
Forward Voltage 1.5V
Continuous forward current- Max 15mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-DIP Gull Wing
Win Source Part Number 1042643-HCPL-2630-500E
Popularity Medium
Supply and Demand Status Sufficient
Quantity per package 1k pcs
Ultra Librarian 3D Model Ultra Librarian HCPL-2630-500E CAD Model

Description

The HCPL-2630-500E is a dual channel optocoupler manufactured by Broadcom Limited.

  • Output Type: Open Collector, Schottky Clamped
  • Data Rate: 10MBd
  • Forward Voltage: 1.5V
  • Isolation Voltage: 3750Vrms
  • Common Mode Transient Immunity: 5kV/μs
  • Propagation Delay: 100ns, 100ns (tpLH / tpHL max)
  • Supply Voltage Range: 4.5V to 5.5V
  • Channel Output Current: 50mA
  • Popularity: popular
  • Supply and Demand Status: sufficient
  • Package: 8-DIP gull wing
