HCNW2211-500E Real Image HCNW2211-500E Real Image
Same model may have multiple batches, images only for reference.
HCNW2211-500E Real Image HCNW2211-500E Real Image
HCNW2211-500E Real Image HCNW2211-500E Real Image
Same model may have multiple batches, images only for reference.

HCNW2211-500E

Part No HCNW2211-500E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description Optocoupler Logic-Out Totem-Pole DC-IN 1-CH 8-Pin PDIP W SMD T/R / OPTOISO 5KV PUSH PULL 8DIP GW
Datasheet
HCNW2211-500E Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 5000Vrms
Common Mode Transient Immunity (Min) 10kV/μs
Input Type DC
Output Type Push-Pull, Totem Pole
Channel Output Current 25mA
Data Rate 5MBd
Propagation Delay tpLH / tpHL (Max) 180ns, 160ns (Typ)
Rise and Fall Time 30ns, 7ns
Forward Voltage 1.5V
Continuous forward current- Max 10mA
Supply Voltage - Operating 4.5 V to 20 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-DIP Gull Wing
Win Source Part Number 087922-HCNW2211-500E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 750
Family Name HCNW2211
Introduction Date November 01, 2003
ECCN EAR99
Country of Origin Singapore, Thailand
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian HCNW2211-500E CAD Model

Description

The Broadcom Limited 087922-HCNW2211-500E is an isolator.

  • Output Type: Push-Pull, Totem Pole
  • Data Rate: 5MBd
  • Common Mode Transient Immunity (Min): 10kV/μs
  • Propagation Delay tpLH / tpHL (Max): 180ns, 160ns (Typ)
  • Channel Output Current: 25mA
  • Status: Active
  • Popularity: High
  • Supply/Demand: Balanced
  • Package: Reel - TR (750 pcs)
