ASSR-1218-503E Real Image ASSR-1218-503E real image15145 ASSR-1218-503E real image15146
Same model may have multiple batches, images only for reference.
ASSR-1218-503E Real Image ASSR-1218-503E real image15145 ASSR-1218-503E real image15146
ASSR-1218-503E Real Image ASSR-1218-503E real image15145 ASSR-1218-503E real image15146
Same model may have multiple batches, images only for reference.

ASSR-1218-503E

Part No ASSR-1218-503E
Manufacturer Broadcom Limited
Catalog Solid State Relays
Description RELAY SSR SPST SGL 0.20A 4SOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Circuit SPST-NO (1 Form A)
Output Type AC, DC
Max On Resistance 10 Ohm
Load Current 200mA
Voltage - Input 1.3VDC
Voltage - Load 0 to 60 V
Mounting SMD (SMT)
Termination Style Gull Wing
Case / Package 4-SO
Relay Type Relay
Win Source Part Number 1018641-ASSR-1218-503E
Popularity Medium
Supply and Demand Status Sufficient
Quantity per package 1,500
Ultra Librarian 3D Model Ultra Librarian ASSR-1218-503E CAD Model

Description

The Broadcom Limited 1018641-ASSR-1218-503E is a relay type product that has a SPST-NO (1 Form A) circuit.

  • Circuit: SPST-NO (1 Form A)
  • Supply and Demand Status: sufficient
  • Package Quantity: 1,500
  • Maximum On Resistance: 10 Ohm
  • Voltage Input: 1.3VDC
  • Output Type: AC and DC
  • Load Current: 200mA
  • Voltage Load: 0 to 60 V
  • Mounting: SMD (SMT)
  • Termination Style: Gull Wing
