ACPL-217-56AE Real Image ACPL-217-56AE real image567
Same model may have multiple batches, images only for reference.
ACPL-217-56AE Real Image ACPL-217-56AE real image567
ACPL-217-56AE Real Image ACPL-217-56AE real image567
Same model may have multiple batches, images only for reference.

ACPL-217-56AE

Part No ACPL-217-56AE
Manufacturer Broadcom Limited
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 3KV TRANS 4SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3000Vrms
Minimum DC Current Transfer Ratio 80% @ 5mA
Maximum DC Current Transfer Ratio 160% @ 5mA
Switching Turn-On and Turn-Off Time 3μs, 3μs
Rise and Fall Time 2μs, 3μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.2V
Continuous forward current- Max 50mA
Vce Saturation (Max) 400mV
Temperature Range - Operating -55°C to 110°C
Mounting SMD (SMT)
Case / Package 4-SO
Win Source Part Number 076789-ACPL-217-56AE
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name ACPL-217
Introduction Date April 17, 2007
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2023
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian ACPL-217-56AE CAD Model

Description

Product Overview

The ACPL-217-56AE is crafted for advanced electrical isolation needs, offering optimal protection and reliability in demanding environments.

Features and Benefits

  • Quick response time: Ideal for systems requiring rapid signal processing.
  • High isolation voltage: Protects sensitive components from surges and spikes.
  • Versatile design: Easily integrates into various circuit applications.

Applications

  • Renewable energy converters
  • Safety systems in machinery
  • Building control applications

Additional Details

With its high versatility and robust protection features, the ACPL-217-56AE is designed to meet the complex needs of modern electronic applications, ensuring operational efficiency and safety.
