6N136-500E Broadcom Limited 6N136-500E Real Image1 6N136-500E Real Image2
Same model may have multiple batches, images only for reference.
6N136-500E Broadcom Limited 6N136-500E Real Image1 6N136-500E Real Image2
6N136-500E Broadcom Limited 6N136-500E Real Image1 6N136-500E Real Image2
Same model may have multiple batches, images only for reference.

6N136-500E

Part No 6N136-500E
Manufacturer Broadcom Limited
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 3.75KV TRANS W/BASE 8SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 19% @ 16mA
Maximum DC Current Transfer Ratio 50% @ 16mA
Switching Turn-On and Turn-Off Time 200ns, 600ns
Input Type DC
Maximum Output Voltage 20V
Channel Output Current 8mA
Forward Voltage 1.5V
Continuous forward current- Max 25mA
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 006376-6N136-500E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 1k pcs
Ultra Librarian 3D Model Ultra Librarian 6N136-500E CAD Model

Description

Product Overview

The 6N136-500E optocoupler is designed for applications requiring secure data transmission and isolation. It features a fast response time, making it ideal for high-speed communication systems.

Features and Benefits

  • 5,000 Vrms isolation voltage.
  • High-speed transmission capabilities.
  • Low signal distortion.
  • Wide frequency response range.

Applications

  • Telecommunication equipment.
  • Computer peripheral interfaces.
  • Control systems.
