TIC246M-S real image
Same model may have multiple batches, images only for reference.

TIC246M-S

Part No TIC246M-S
Manufacturer Bourns Inc.
Catalog Triacs
Description TRIAC 600V 16A TO220 / TRIAC 600V 125A 3-Pin(3+Tab) TO-220
Datasheet
TIC246M-S Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Bourns Inc.
Packaging Tube
Part Status Obsolete(EOL)
Triac Type Standard
Voltage - Off State 600V
Current - On State (It (RMS)) (Maximum) 16A
Voltage - Gate Trigger (Vgt) (Maximum) 2V
Current - Non Rep. Surge 50, 60Hz (Itsm) 125A @ 50Hz
Current - Gate Trigger (Igt) (Maximum) 50mA
Current - Hold (Ih) (Maximum) 40mA
Configuration Single
Operating Temperature Range -40°C ~ 110°C (TC)
Mounting Style Through Hole
Package TO-220-3
Manufacturer Package TO-220
Win Source Part Number 796775-TIC246M-S
Popularity Medium
Supply and Demand Status Limited
Family Name TIC246M
Introduction Date May 23, 1993
Country of Origin Philippines
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian TIC246M-S CAD Model

Description

The Bourns Inc. TIC246M-S is a through-hole triac from Bourns Inc..

  • Voltage - Off-State: 600V
  • Current - Non-Rep. Surge 50, 60Hz (Itsm): 125A @ 50Hz
  • Current - On-State (It (RMS)) (Maximum): 16A
  • Voltage - Gate Trigger (Vgt) (Maximum): 2V
  • Current - Gate Trigger (Igt) (Maximum): 50mA
  • Current - Hold (Ih) (Maximum): 40mA
  • Package: TO-220-3
  • Applications: AC solid-state switches, industrial power tools, home appliances
