SRP7030-R33M

Part No SRP7030-R33M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Description Shielded Power Inductors
Datasheet
SRP7030-R33M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer Bourns Inc.
Series SRP7030
Packaging Reel - TR
Type Wirewound
Material - Core Iron
Inductance 330nH
Tolerance ±20%
Current Rating 20A
Current - Saturation 30A
Shielding Shielded
DC Resistance (DCR) 3.9 mOhm Max
Operating Temperature Range -55°C ~ 150°C
Test Frequency 100kHz
Mounting SMD
Package Nonstandard
Size 0.307" L x 0.276" W (7.80mm x 7.00mm)
Height - Seated (Maximum) 0.126" (3.20mm)
Win Source Part Number 1258823-SRP7030-R33M
Manufacturer Homepage www.bourns.com
Popularity Medium
Supply and Demand Status Limited
Family Name SRP7030
Introduction Date January 21, 2008
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2019
Ultra Librarian 3D Model Ultra Librarian SRP7030-R33M CAD Model

Description

The Bourns Inc. SRP7030-R33M is a wirewound inductor with a current rating of 20A and an inductance of 330nH.

  • Current Rating: 20A
  • Inductance: 330nH
  • Shielded: Yes
  • Maximum DC Resistance: 3.9 mOhm
  • Temperature Range: -55°C to 150°C
  • Supply and Demand Status: Limited
  • Manufacturer: Bourns Inc.
