CD143A-SR2.8 Bourns Inc. CD143A-SR2.8 Real Image CD143A-SR2.8 real image
Same model may have multiple batches, images only for reference.
CD143A-SR2.8 Bourns Inc. CD143A-SR2.8 Real Image CD143A-SR2.8 real image
CD143A-SR2.8 Bourns Inc. CD143A-SR2.8 Real Image CD143A-SR2.8 real image
Same model may have multiple batches, images only for reference.

CD143A-SR2.8

Part No CD143A-SR2.8
Manufacturer Bourns Inc.
Catalog TVS - Diodes
Description CD143A-SR2.8~3.3 - Steering/TVS Diode Array Series
Datasheet
CD143A-SR2.8 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Bourns Inc.
Packaging Reel - TR
Type Steering (Rail to Rail)
Unidirectional Channels 2
Voltage - Reverse Standoff (Typ) 2.8V
Minimum Breakdown Voltage 3V
Maximum Clamping Voltage 5V
Current - Peak Pulse (10/1000μs) 12A (8/20μs)
Power - Peak Pulse 200W
Power Line Protection Yes
Applications Ethernet
Capacitance @ Frequency 4.5pF @ 1MHz
Operating Temperature Range -55°C ~ 125°C (TJ)
Mounting SMD
Package TO-253-4, TO-253AA
Manufacturer Package SOT-143
Win Source Part Number 1159483-CD143A-SR2.8
Manufacturer Homepage www.bourns.com
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Communications & Networking, Computers & Computer Peripherals, Portable Devices, Imaging, Video & Vision, Industrial
Ultra Librarian 3D Model Ultra Librarian CD143A-SR2.8 CAD Model

Description

This is a CD143A-SR2.8 product from Bourns Inc.

  • Type: Steering (rail to rail)
  • Voltage - Reverse Standoff (Typ): 2.8V
  • Current - Peak Pulse (10/1000μs): 12A (8/20μs)
  • Power - Peak Pulse: 200W
  • Feature: Power Line Protection
  • Capacitance @ Frequency: 4.5pF @ 1MHz
  • Application: Ethernet
  • Operating Temperature: -55°C ~ 125°C (TJ)
  • Package: TO-253-4, TO-253AA
  • Mounting Type: Surface Mount
  • Channels: 2 Unidirectional
  • Breakdown Voltage (Min): 3V
  • Manufacturer: Bourns Inc.
  • Popularity: Medium
  • Supply and Demand: Balanced
