The 4816P-001-121 is a thick film resistor network manufactured by Bourns Inc. This SIP (Single In-line Package) resistor network is designed for a variety of current limiting, voltage dividing, and pull-up/pull-down applications. It is commonly used to reduce the number of components and board space required compared to using individual discrete resistors.

Applications

• Digital circuits: Pull-up/pull-down resistors for microcontrollers and logic gates.
• Current limiting: Protecting LEDs and other sensitive components from excessive current.
• Voltage division: Creating voltage dividers for sensor interfaces and analog circuits.
• Telecommunications equipment.
• Consumer electronics.

Features

• SIP (Single In-line Package): Space-saving design.
• Thick film technology: Provides stable and reliable resistance values.
• Isolated resistors: Each resistor is electrically isolated from the others.
• RoHS compliant: Environmentally friendly.
• Various resistance values available.

Benefits

• Reduced component count: Simplifies circuit design and assembly.
• Improved reliability: Consistent resistor matching and performance.
• Space savings: Compact package for high-density designs.
• Lower assembly costs: Easier to place and solder compared to discrete resistors.
• Stable performance over temperature.
