The AK8973N is a small, low-power 3-axis electronic compass IC from Asahi Kasei Microsystems (AKM). It integrates three magnetic sensors for detecting magnetic field strength in the X, Y, and Z axes, allowing for accurate heading determination. The device features an internal oscillator, analog-to-digital converters (ADCs), and control logic, all within a compact package.

Applications:

• Smartphones
• Tablets
• Wearable devices (smartwatches, fitness trackers)
• Navigation systems
• Robotics
• Gaming controllers
• Augmented reality (AR) and virtual reality (VR) applications

Features:

• 3-axis magnetic field detection
• High accuracy and resolution
• Low power consumption
• I2C interface for communication
• Internal oscillator
• Compact package
• Wide operating temperature range
• Built-in self-test function

Benefits:

• Precise heading information: Enables accurate orientation sensing for navigation and other applications.
• Low power consumption: Extends battery life in portable devices.
• Small form factor: Allows for easy integration into compact devices.
• Simplified system design: The I2C interface simplifies communication with microcontrollers and other system components.
• Robust performance: The built-in self-test function ensures reliable operation.

The AK8973N utilizes AKM's advanced magnetic sensor technology to achieve high sensitivity and low noise. It communicates with a host processor via the I2C serial interface, allowing for easy configuration and data retrieval. The device provides raw magnetic field data, which can be processed by the host to calculate heading and other orientation parameters. The AK8973N's low power consumption makes it ideal for battery-powered applications. Furthermore, the integration of calibration features helps to compensate for hard and soft iron distortions, improving accuracy in real-world environments. It operates typically from a 3.0V supply, making it compatible with various electronic systems.
