Product Overview: OP284ESZ-REEL by Analog Devices Inc.

The OP284ESZ-REEL is a precision operational amplifier from the renowned manufacturer Analog Devices Inc., crafted for a broad range of applications that require high accuracy and stability. This operational amplifier is part of a product family known for its excellent performance in terms of speed and power efficiency, making it an ideal choice for designers who require an op-amp with a good balance between cost and capabilities.

The OP284ESZ-REEL comes in a surface-mount package and is supplied on a reel, which is suitable for automated assembly processes, thus catering to mass production requirements. This component is characterized by its rail-to-rail output swing, which allows for the maximum possible dynamic range at the output. This feature is particularly beneficial in single-supply applications or where the supply voltage is limited.

Key Features and Benefits

• Wide Power Supply Range: The device can operate from a single supply of 3V to 36V or dual supplies of ±1.5V to ±18V, providing flexibility in various circuit designs.
• Low Power Consumption: With its low power requirements, the OP284ESZ-REEL is an excellent choice for battery-powered devices and portable applications.
• High Precision: Its low offset voltage and low noise contribute to the high precision of the amplifier, making it suitable for high-end instrumentation and data acquisition systems.
• High Common-Mode Rejection Ratio (CMRR): The device offers excellent rejection of common-mode signals, enhancing the accuracy of differential measurements.
• Wide Bandwidth: The OP284ESZ-REEL provides a bandwidth that is sufficient for a wide array of applications, from audio to control systems.

The operational amplifier is also protected against over-temperature conditions and includes features like no phase reversal, which ensures reliable operation even when the input voltage exceeds the power supply levels.

Whether you are designing precision filters, low noise amplifiers, or need a general-purpose op-amp for your electronic circuit, the OP284ESZ-REEL from Analog Devices Inc. offers a compelling combination of performance, reliability, and versatility that can meet the demands of your next project.
