Product Overview: ADR02AUJZ-REEL7 from Analog Devices Inc.

The ADR02AUJZ-REEL7 is a high-precision voltage reference component manufactured by Analog Devices Inc., renowned for its accuracy and stability. This product is a part of the ADR02 series, which is designed to offer a compact and reliable solution for applications requiring a fixed reference voltage. The ADR02AUJZ-REEL7 is specifically packaged in a convenient 7-inch reel, making it ideal for automated manufacturing processes.

Key Features and Benefits:

• Precision Voltage: The ADR02AUJZ-REEL7 provides a 5.0V output with an initial accuracy of ±0.1%.
• Low Temperature Coefficient: It has an excellent temperature coefficient of 10 ppm/°C (max), ensuring stable performance over a wide temperature range.
• Long-Term Stability: This voltage reference demonstrates superior long-term stability, with a typical drift of less than 150 ppm/√kHrs, making it reliable for critical applications.
• Low Noise: With a low noise performance of 1.0 µV p-p/V (0.1 Hz to 10 Hz), the ADR02AUJZ-REEL7 is suitable for high-precision analog circuits.
• Wide Supply Range: It operates from a wide supply range of 7 V to 18 V, providing flexibility in various power supply configurations.
• Sink and Source Capability: The device can source or sink up to 10 mA, making it versatile for different load conditions.
• Compact Package: The ADR02AUJZ-REEL7 comes in a small outline SOT-23 package, which is ideal for space-constrained applications.

Applications:

The ADR02AUJZ-REEL7 is suitable for a diverse range of applications where a stable reference voltage is critical. These include:

• Data Acquisition Systems
• Precision Instrumentation
• Automotive Electronics
• Industrial Control Systems
• Battery-Powered Devices
• Portable Medical Equipment

With its high precision, stability, and low power consumption, the ADR02AUJZ-REEL7 is an excellent choice for engineers and designers looking to enhance the performance of their electronic systems. Analog Devices Inc. ensures that this voltage reference meets stringent quality standards, providing reliable and consistent performance for your advanced circuit designs.
