Analog Devices Inc. ADG725BSUZ CMOS Analog Multiplexer

The ADG725BSUZ is a high-performance CMOS analog multiplexer from Analog Devices Inc., a leader in the design and manufacturing of precision high-performance integrated circuits. This device is part of the ADG72x series, which is renowned for its robust design, low power consumption, and high switching speeds. The ADG725BSUZ offers a dual 4-channel multiplexing configuration, making it an ideal choice for data acquisition systems, communication systems, and various industrial applications where multiple signal channels need to be routed to a single data acquisition point.

With a single 3 V to 5 V power supply, the ADG725BSUZ operates efficiently and integrates seamlessly into a wide range of electronic systems. Its low on-resistance of typically 2.5 ohms and flatness of 0.5 ohms across the signal range ensure minimal signal distortion and high signal integrity, making it particularly suitable for precision analog applications. The on-resistance is also matched between channels to within 0.1 ohms and is very stable over the full signal and supply range, providing consistent performance and ease of use.

This multiplexer is designed with a 1.8 V logic-compatible digital interface, which allows for direct connection to microcontrollers and digital signal processors with lower voltage logic levels. This feature simplifies the system design and reduces the need for additional level-shifting components. The ADG725BSUZ also boasts a low power dissipation, with a typical power consumption of less than 1 µW, making it an excellent choice for power-sensitive applications.

The device is provided in a compact 20-lead TSSOP (Thin Shrink Small Outline Package), which is suitable for space-constrained applications. The package is designed for surface-mount technology, ensuring easy integration into modern printed circuit board designs. The ADG725BSUZ's enhanced electrostatic discharge (ESD) protection further ensures reliability and robustness in harsh environments.

In summary, the ADG725BSUZ by Analog Devices Inc. offers a combination of high performance, low power consumption, and ease of use, making it a versatile choice for designers looking to implement accurate and efficient analog signal routing in their systems.
